How To Integrate Razorpay Payment Gateway In Django And React For The Checkout Use Case?

Published on

To accept payment from customers using our web application. We need to integrate a payment gateway into our application. There are so many payment gateway providers out there but in this article, we are going to use Razorpay to set up a simple payment gateway with React.js and Django.

Introduction:

Razorpay is one of the modern payment gateways widely used in India. It is more reliable than its compitors. Also, it is developer-friendly and easy to integrate with any technology stack. Also, they provide so many modes of payment like UPI, Debit cards, Credit cards, Internet banking and digital wallets and QR scanner code.

How it works ( Sequence Diagram ) :

Prerequisites:

Razorpay public and private keys ( How to get Razorpay public and private keys? )
Basic Django project setup
Basic React.js project setup

Flow Diagram:

Steps:

In this tutorial the payments are done in Test mode, not in production mode.

The source code for both Django and react are given here: https://github.com/episyche/razorpay_django_reactjs_example

Setup instructions for Django and React.js are given in the Github Readme file.

Step 1: Setup a Razorpay account and generate API keys(public and private keys)

API keys are a unique identification number used to link your Razorpay account with any development platform like Python, Java, Ruby, Node.js etc.

If you don’t have a Razorpay account click here (How to create a Razorpay account ?)
If you don’t have Razorpay API Keys click here (How to generate Razorpay API keys ?)

Step 2: Set up a basic Django project.

Create an empty folder with the project name.

1mkdir <project-name>
2cd <project-name>
3
4For example:
5mkdir cake-shop
6cd project-folder

Inside the folder cake-shop(project-folder) create the Django project

1django-admin startproject core .

a. core: main app name.

b. (.) the dot symbol at the end indicates not to create a new folder. Generate files on the working directory.

c. Once the files are generated, It will be looking like the below screenshot example.

Step 3: Create a new Django app for the payment process “payment_razorpay”.

Create a Django app for handling payment logic. The name of the app is “payment_razorpay”.

1cd /<project-folder>
2
3for example :
4cd /cake-shop

1cd /cake-shop python3 manage.py startapp payment_razorpay

a. After executing the above command an app named “payment_razorpay” will be created. An example screenshot is given below:

Add the payment_razorpay app to the INSTALLED_APPS list in settings.py

cake_shop/core/settings.py  (<project-folder>/core/settings.py)

1
2INSTALLED_APPS = [
3    'django.contrib.admin',
4    'django.contrib.auth',
5    'django.contrib.contenttypes',
6    'django.contrib.sessions',
7    'django.contrib.messages',
8    'django.contrib.staticfiles',
9    'payment_razorpay', # <<< newly added line
10]

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/core/settings.py

Add a new URL path for the payment_razorpay app, to the base app ( main app ) urls.py file.

cake_shop/core/urls.py (<project-folder/core/urls.py)

1from django.contrib import admin
2from django.urls import path, include  # <<< newly added line
3
4urlpatterns = [
5    path('admin/', admin.site.urls),
6    path('payment/', include('payment_razorpay.urls')), # <<< newly added line
7]

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/core/urls.py

Create a new urls.py file under the payment_razorpay app that we just created.

Step 4: Install Razorpay using pip.

Install Razorpay SDK using pip

1pip install razorpay

Step 5: Create a new function API “new_order” under the payment_razorpay app to handle new payment requests.

<project_folder> payment_razorpay > views.py > new_order (function API)

cake-shop > payment_razorpay > views.py > new_order (function API)

Create a function API “new_order” to handle the new payment requests from the front end.

1from unicodedata import name
2from django.shortcuts import render
3import razorpay
4from django.http import JsonResponse
5from django.views.decorators.csrf import csrf_exempt
6
7
8razorpay_client = razorpay.Client(auth=("rzp_test_dFP2CS0ZMKdXFz", "gaZHYtCOVJ2u2oPcS0RGTZm6"))
9
10@csrf_exempt
11def new_order(request):
12    if request.method == "POST":
13
14        print("", request.POST['price'])
15        amount = int(request.POST['price'])
16        product_name = request.POST['product_name']
17
18        new_order_response = razorpay_client.order.create({
19                        "amount": amount*100,
20                        "currency": "INR",
21                        "payment_capture": "1"
22                      })
23
24        response_data = {
25                "callback_url": "http://127.0.0.1:8000/payment/callback",
26                "razorpay_key": "rzp_test_dFP2CS0ZMKdXFz",
27                "order": new_order_response,
28                "product_name": product_name
29        }
30
31        print(response_data)
32
33        return JsonResponse(response_data)

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/payment_razorpay/views.py

Add a new URL path for the “new_order” API in the urls.py file under the payment_razorpay app.

cake_shop/payment_razorpay/urls.py (<project-folder>/payment_razorpay/urls.py)

1from . import views
2from django.urls import path
3
4urlpatterns = [
5    path("new-order", views.new_order)
6]

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/payment_razorpay/urls.py

Step 6: Create another function API to handle the response from the payment gateway.

To handle the response from Razorpay payment gateway create a new function API named “order_callback“.
After successful payment, Razorpay sends payment-related information to a backend API that we specified in the callback URL. Using the data we get from Razorpay we can verify the payment status and write business logic according to the payment status.
The data we get from Razorpay is given below:

1{
2  "razorpay_payment_id": "pay_29QQoUBi66xm2f",
3  "razorpay_order_id": "order_9A33XWu170gUtm",
4  "razorpay_signature": "9ef4dffbfd84f1318f6739a3ce19f9d85851857ae648f114332d8401e0949a3d"
5}

1@csrf_exempt
2def order_callback(request):
3    if request.method == "POST":
4        if "razorpay_signature" in request.POST:
5            payment_verification = razorpay_client.utility.verify_payment_signature(request.POST)
6            if payment_verification:
7                return JsonResponse({"res":"success"})
8                # Logic to perform is payment is successful
9            else:
10                return JsonResponse({"res":"failed"})
11                # Logic to perform is payment is unsuccessful

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/payment_razorpay/views.py

Step 7: Install CROS in Django

Set up CROS in Django, In order to avoid CROS problems between the frontend(React.js) and backend (Django).
pip install

1pip install django-cors-headers

Add CROS to MIDDLEWARE in settings.py

cake-shop<project-name>/ core / settings.py

1MIDDLEWARE = [
2    'django.middleware.security.SecurityMiddleware',
3    'django.contrib.sessions.middleware.SessionMiddleware',
4    'django.middleware.common.CommonMiddleware',
5    'django.middleware.csrf.CsrfViewMiddleware',
6    'django.contrib.auth.middleware.AuthenticationMiddleware',
7    'django.contrib.messages.middleware.MessageMiddleware',
8    'django.middleware.clickjacking.XFrameOptionsMiddleware',
9    'corsheaders.middleware.CorsMiddleware', # <<< new line added
10]

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/core/settings.py

Add another variable at the end of the setings.py file.

cake-shop<project-name>/ core / settings.py

1CORS_ORIGIN_ALLOW_ALL = True # <<< append to the end of the settings.py

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/backend/core/settings.py

Step 8: Integrate Razorpay payment gateway to React(frontend)

In this tutorial, a new component is created “Card.jsx”. Here we write the logic to handle the Razorpay payment gateway process.
There is no package available in npm to install for Razorpay. We have to integrate the Razorpay from CDN using useEffect hook. The example code is given below.

1const loadScript = (src) => {
2        return new Promise((resolve) => {
3          const script = document.createElement("script");
4          script.src = src;
5          script.onload = () => {
6            resolve(true);
7          };
8          script.onerror = () => {
9            resolve(false);
10          };
11        document.body.appendChild(script);
12      });
13    };
14
15    useEffect(() => {
16        loadScript("https://checkout.razorpay.com/v1/checkout.js");
17    });

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/frontend-reactjs/src/Card.jsx

In react.js to initialize the Razorpay payment gateway, we need some additional information they are provided from the backend. Here is the list of the information we need :
- Razorpay key id
- Amount
- Product name
- currency
- callback URL ( Django URL)
- order_id

1import Book1Img from './img/book1.png';
2import Book2Img from './img/book2.png';
3import { useEffect } from 'react';
4
5export default function Card(){
6
7    const loadScript = (src) => {
8        return new Promise((resolve) => {
9          const script = document.createElement("script");
10          script.src = src;
11          script.onload = () => {
12            resolve(true);
13          };
14          script.onerror = () => {
15            resolve(false);
16          };
17        document.body.appendChild(script);
18      });
19    };
20
21    useEffect(() => {
22        loadScript("https://checkout.razorpay.com/v1/checkout.js");
23    });
24
25
26    function makePayment(e, price, book_name){
27
28        e.preventDefault();
29
30
31        let formData = new FormData();
32        formData.append('price', price);
33        formData.append('product_name', book_name);
34
35        async function paymentGateway() {
36            const url = 'http://127.0.0.1:8000/payment/new-order' // <<< new-order backend api url path
37            const res = await fetch(url, { method: 'POST', body: formData ,
38            })
39            const jsonRes = await res.json()
40            return jsonRes
41        }
42
43        paymentGateway().then((res) =>{
44            //_________ call razorpay gateway ________
45            var options = {
46                "key": res['razorpay_key'],
47                "amount": res['order']['amount'],
48                "currency": res['order']['currency'],
49                "callback_url": res['callback_url'],
50                prefill: {
51                    "email": "nosob88243@xitudy.com",
52                    "contact": "1234567890"
53                },
54                "name": res['product_name'],
55                "order_id": res['order']['id'],
56            };
57
58            var rzp1 = new window.Razorpay(options);
59            rzp1.open();
60        })
61
62    }
63
64
65    return(
66        <>
67            <section className='flex justify-center mt-52'>
68                <div className='rounded px-10 py-2 text-center drop-shadow-lg bg-zinc-50'>
69                    <h2 className='text-3xl mb-5'>Educated</h2>
70                    <img className='w-48' src={Book1Img} alt="" />
71                    <button type='button' className="mt-12 inline-flex items-center px-2.5 py-1.5 border border-transparent text-sm font-medium rounded shadow-sm text-white bg-indigo-600 hover:bg-indigo-700 focus:outline-none focus:ring-2 focus:ring-offset-2 focus:ring-indigo-500"
72                     onClick={e=>{makePayment(e, 500, "Educated")}}
73                     >Buy 500</button>
74                </div>
75                <div className='rounded px-10 py-2 text-center drop-shadow-lg bg-zinc-50 ml-10'>
76                    <h2 className='text-3xl mb-5'>Atomic Habit</h2>
77                    <img className='w-48' src={Book2Img} alt="" />
78                    <button className="mt-12 inline-flex items-center px-2.5 py-1.5 border border-transparent text-sm font-medium rounded shadow-sm text-white bg-indigo-600 hover:bg-indigo-700 focus:outline-none focus:ring-2 focus:ring-offset-2 focus:ring-indigo-500"
79                    onClick={e=>{makePayment(e, 800, "Atomic Habit")}}
80                    >Buy 800</button>
81                </div>
82            </section>
83        </>
84    )
85
86}

Sample code for the above use case can be found in the following GitHub URL.

https://github.com/episyche/razorpay_django_reactjs_example/blob/main/frontend-reactjs/src/Card.jsx

Step 9: Run both Django and React.js development servers.

To run Django development server:

1cd <project-folder>
2
3for example:
4cd cake-shop

1python3 manage.py runserver

To run React.js development server:

1cd <project-folder>
2
3for example:
4cd frontend

1npm start

Result :

Select any one product from the web page

Select UPI ID as the payment mode.

Enter the following UPI ID provided by Razorpay for Testing purposes. (success@razorpay)

After successful payment, you will get a success message as a response from the backend (Django).

Comments

WebOptbeta

WebOpt.ai is a powerful AI Chrome extension that revolutionizes UI/UX and SEO testing for websites. It provides real-time insights and actionable recommendations to enhance site performance using AI.

Try now

interested topics

Episyche

How To Integrate Razorpay Payment Gateway In Django And React For The Checkout Use Case?

Introduction:

Prerequisites:

Flow Diagram:

Steps:

Step 1: Setup a Razorpay account and generate API keys(public and private keys)

Step 2: Set up a basic Django project.

Step 3: Create a new Django app for the payment process “payment_razorpay”.

Step 4: Install Razorpay using pip.

Step 5: Create a new function API “new_order” under the payment_razorpay app to handle new payment requests.

Step 6: Create another function API to handle the response from the payment gateway.

Step 7: Install CROS in Django

Step 8: Integrate Razorpay payment gateway to React(frontend)

Step 9: Run both Django and React.js development servers.

Result :

WebOptbeta
